2.8 Lac / Piece
| Business Type | Manufacturer, Supplier, Retailer |
| Origin Of Country | India |
| Type | All Geared Radial Drilling Machine |
| Drilling Capacity In M.S. | 40 mm |
| Click to view more | |
Product Details
Drilling Capacity In C.I.
45 mm
Tapping In M.S.
M20
Rough Boring In M.S.
75 mm
Spindle Hole Taper
MT-4
Spindle Travel
250 mm
Spindle Speed
75 - 2000 RPM
Diameter Of Ram
78 mm
Spindle Autofeed Ranges
0.05 - 0.08 Mm/rev
Max./Min. Distance Spindle Nose To Base
850 / 50 mm
Max./Min. Distance Spindle Center To Column
520 / 385 mm
Table Size
305 X 305 mm
Max. Drilling Radius
605 Mm
Machine Measurement (L X B X H)
1350 X 850 X 1825 mm
Column Diameter
150 mm
Distance From Spindle Nose To Base
850 mm
Work Table
305 X 305 X 385 mm
Motor
2 HP (3 Phase)
Drill Head Motor
1.5 HP / 960 RPM
Elevating Motor
0.5 HP / 1440 RPM
Standard Accessories
Coolant Tank, Electrical Panel Board, V-belt Drive
Product Code
152
